AMD Ryzen™ 9 9950X3D2 Dual Edition Desktop Processor
AMD Ryzen™ 9 9950X3D2 Dual Edition Desktop Processor
The World's First Dual AMD 3D V-Cache™ Technology-Based Desktop Processor — built for creators and developers who push systems hard. Powered by 2nd Gen AMD 3D V-Cache™, expanded on-chip memory reduces latency and keeps demanding workflows responsive, from complex timelines and large datasets to parallel builds and simulations. When it's time to play, the same cache advantage delivers smooth, immersive gaming without forcing you to choose between work and performance.
Key Features
- 16 Cores / 32 Threads — Zen 5 architecture built on TSMC 4nm FinFET for maximum performance per watt.
- Up to 5.6 GHz Max Boost with 4.3 GHz base clock and Precision Boost 2.
- 192 MB L3 Cache featuring Dual AMD 3D V-Cache™ Technology for massive data locality.
- AM5 Socket compatibility with AMD X870E, X870, B850, X670E, X670, B650E, B650, A620, B840 chipsets.
- DDR5 Memory up to 256 GB, dual-channel, with AMD EXPO™ memory overclocking.
- PCIe® 5.0 with 24 usable lanes for next-generation GPUs and NVMe SSDs.
- Unlocked Multiplier with Precision Boost Overdrive, Curve Optimizer, and AMD Ryzen™ Master support.
- Integrated AMD Radeon™ Graphics for display output without a discrete GPU.
Technical Specifications
| Architecture | Zen 5 |
| CPU Cores / Threads | 16 / 32 |
| Max Boost Clock | Up to 5.6 GHz |
| Base Clock | 4.3 GHz |
| L1 Cache | 1280 KB |
| L2 Cache | 16 MB |
| L3 Cache | 192 MB (Dual 3D V-Cache) |
| Default TDP | 200 W |
| Max Operating Temp | 95°C |
| Process Node (CPU / I/O) | TSMC 4nm FinFET / TSMC 6nm FinFET |
| Socket | AM5 |
| Supported Chipsets | A620, B650, B650E, B840, B850, X670, X670E, X870, X870E |
| Memory Type | DDR5 (UDIMM), Dual-Channel |
| Max Memory | 256 GB |
| Max Memory Speed | DDR5-5600 (2 DIMMs) / DDR5-3600 (4 DIMMs) |
| ECC Support | Yes (requires motherboard support) |
| PCIe Version | PCIe® 5.0 |
| PCIe Lanes (Total / Usable) | 28 / 24 |
| Integrated Graphics | AMD Radeon™ Graphics (2 cores @ 2200 MHz) |
| Instruction Set Extensions | AVX-512, AVX2, AVX, AES, FMA3, SSE4.2 |
| Unlocked for Overclocking | Yes |
| Thermal Solution | Not Included (liquid cooler recommended) |
