Cooler Master GX II 850Watts 80 Plus Gold ATX 3.0 Full Modular Power Supply (MPX-8503-AFAG-2BUS)
Product Description
Power your rig with the Cooler Master GX II 850W 80 Plus Gold ATX 3.0 PSU. This full-modular design ensures neat cable management and efficient energy use. Built for reliability, it supports PCIe 5.0 GPUs, offers superior thermal performance, and includes advanced protections for stable and powerful performance in high-demand systems.
Product Specifications
| Model | 850: MPX-8503-AFAG-2*** |
| ATX Version | ATX 12V Ver. 3.0 |
| PFC | Active PFC |
| Input Voltage | 100-240V |
| Input Current | 10-5A |
| Input Frequency | 50-60Hz |
| Dimensions (L x W x H) | 160 x 150 x 86 mm |
| Fan Size | 120mm |
| Fan Bearing | HDB |
| Fan Speed | 2500 RPM |
| Efficiency | ≥90% @ Typical Load |
| 80 PLUS Rating | 80 PLUS Gold |
| ErP 2014 Lot 3 | Yes |
| Operating Temperature | 0-40°C |
| Power Good Signal | 100 - 150 ms |
| Hold Up Time | ≥16ms at 80% Load |
| MTBF | >100,000 Hours |
| Protections | OPP/ OVP/ OTP/ OCP/ SCP/ UVP/ Surge & Inrush Protection |
| Regulatory | cTUVus, TUV, CE, FCC, BSMI, CCC, EAC, RCM, UKCA, RoHS2.0 / BIS, KC (Based on region's requests.) |
| ATX 24 Pin Connectors | 1 |
| EPS 4+4 Pin Connectors | 1 |
| EPS 8 Pin Connector | 1 |
| SATA Connectors | 6 |
| Peripheral 4 Pin Connectors | 2 |
| PCI-e 6+2 Pin Connectors | 4 |
| 12VHPWR Connector | 1 |
| Series | GX Series |
| 80 Plus | Gold |
| Modular | Fully Modular |
| Category | Above 750W |
| Form Factor | ATX |
| Watts | 850W |
Â
