Seasonic Prime 1300 watts Fully Modular Platinum Power Supply
| Brand | SeaSonic |
| Series | PRIME 1300W Platinum |
| Model | SSR-1300PD |
| Type | ATX12V / EPS12V |
| Maximum Power | 1300W |
| Fans | 135mm Fluid Dynamic Bearing Fan |
| Main Connector | 20+4Pin |
| +12V Rails | Single |
| PCI-Express Connector | 12 x 6+2-Pin |
| SATA Power Connector | 12 |
| Modular | Full Modular |
| Energy-Efficient | 80 PLUS PLATINUM Certified |
| Over Voltage Protection | Yes |
| Input Voltage | 100 - 240 V |
| Input Frequency Range | 50/60 Hz |
| Input Current | 15A - 7.5A |
| Output | +3.3V@25A, +5V@25A, +12V@108A, [email protected], +5VSB@3A |
| MTBF | 150,000 hours |
| Approvals | cTUVus, TUV, CB, CCC, BSMI, EAC, Energy Star, RoHS, WEEE, ErP Lot 6, REACH |
| Dimensions | 3.39" x 5.91" x 6.69" |
| Max PSU Length | 170 mm |
| Connectors | 1 x Main Power (24/20 pins) |
| 2 x CPU (8/4 pins) | |
| 12 x PCIe (8/6 pins) | |
| 12 x SATA | |
| 5 x Peripheral | |
| 1 x Floppy | |
| Features | 80 PLUS Platinum certified |
| Micro Tolerance Load Regulation (1 %) | |
| Cable-free Connection Design | |
| Premium Hybrid Fan Control - Fanless until 40 % load | |
| Multi-GPU setup | |
| Gold plated connectors |
Ideal For
- Powering custom-built desktop PCs
- System upgrades and new builds
- Replacing an existing power supply unit
*Specifications are based on manufacturer data. Actual product may vary.
